580W摇头切割灯 AK-PF580MH
Engineered for premium stage performances, featuring precise beam cutting and pattern projection. Ideal for theaters, opera houses, studios, and other venues requiring exceptional lighting precision. Equipped with a high-precision mechanical structure and intelligent thermal management system for silent operation and extended lifespan.
Certifications
Model:AK-PF580MH
580W Oscillating Cutting Light AK-PF580MH
The AK-PF580-MH Pro Cutting Light features high-quality Osram lamps and a precision cutting dimming system. Equipped with CMY color mixing, CTO color temperature adjustment, multi-dimensional prism patterns, and wide-range scanning, it delivers intelligent control, stable performance, and a lightweight, durable design. Ideal for stage performances, weddings, banquets, and various commercial entertainment venues to create precise lighting effects and dynamic visuals.
Suggested Retail Price
¥8500.00/ unit
This price includes 13% VAT and shipping.
Configuration Selection
Technical Specifications
Product Advantages & Technical Highlights
8-Blade Cutting System
独立电动切割刀片，0-100% 无级调节，支持任意角度旋转，精确塑造光斑形状
High-Definition Projection
专业成像透镜组，图案投射边缘锐利无虚边，支持投影片定制
均匀光斑
复眼透镜匀光系统，光斑中心与边缘照度均匀度≥85%，无黑点暗区
多棱镜效果
8-16 棱圆形棱镜，支持连续旋转和往复摆动，创造丰富光束效果
DMX512 Control
支持 RDM 双向通信协议，可实时反馈灯具状态和故障信息
Product Details
Rated Power: 580W
Light Source: 48 2W Osram Bulb
Bulb Life: 2000 hours
Color Temperature: 6500K
Color Rendering Index: Ra ≥ 85
Power interface: 16A power plug
Signal Interface: 3-pin XLR Connector
Control Mode: DMX512, RDM
Channel Mode: 33 international standard DMX512-channel
Display: 2.7-inch touch LCD with Chinese and English support, rotates up to 180 degrees.
Fixed color: 9 colors + white light
Color Mixing System: Independent CMY color mixing system
Color Temperature Adjustment: Independent CTO 2700-650K linear control
Prism Disc: Rotate 3 prisms in either direction.
Fixed pattern: 7 fixed pattern pieces + white circle + water flow effect
Rotating Pattern: 6 interchangeable rotating pattern segments, outer diameter 22.9mm, effective diameter 11mm + dual white circles
Cutting System: 4 independent blades, each dimmable and rotatable up to 120°
Mist System: Light Mist Plate
Zoom system: 2.5°~43° linear focus
Dimming System: 0-100% Linear Adjustment
Strobe System: Fast Strobe, Pulsed Strobe
Horizontal Scan: 540°
Vertical Scan: 270°
Protection Rating: IP20
Operating environment: 0-45°C
Product Size: 380L270W640H(mm)
Net Weight: 22kgs
Product Design: Flame-retardant, heat-resistant, integrated folding hook
Product specifications, images, and prices are for reference only and subject to change without notice. Please refer to the actual product.
